Carpigiani 193
Twin-twist countertop machines for express gelato, soft serve and frozen yoghurt, producing more than 450 servings of 75 g an hour.
Carpigiani 193 models
Every model has its own page with full features, specifications and photos. Select a model to see it in detail.
Each 193 model
193 Classic
Counter-top twin-twist soft serve machine to produce more than 450 servings of 75 g in one hour.
Power Supply: 400v / 50hz / 3Ph
Cooling System: Air Cooling, Water Cooling
No of Flavours: 2 Flavours +
Mix Delivery System: Pump or Gravity
Flavours: 2+1
193
193 Steel.
Cooling System: Air Cooling, Water Cooling
No of Flavours: 2 Flavours +
Power Supply: 400v / 50hz / 3Ph
Mix Delivery System: Pump
Cylinder Capacity: 1.75 L
193 specifications
| Specification | 193 Classic | 193 |
|---|---|---|
| Power Supply | 400v / 50hz / 3Ph | 400v / 50hz / 3Ph |
| Cooling System | Air Cooling, Water Cooling | Air Cooling, Water Cooling |
| No of Flavours | 2 Flavours + | 2 Flavours + |
| Mix Delivery System | Pump or Gravity | Pump |
| Flavours | 2+1 | 2 + 1 |
| Hourly Production | 435 with the Pump model; 415 with the Gravity model; Note production capacity depends on the mix used and the room temperature (75 g servings) | 485 servings of 75 g; 435 servings of 75 g |
| Tank Capacity | 12+12 with the Pump model; 18+18 with the Gravity model | 12+12 L |
| Cylinder Capacity | 1.75 L | 1.75 L |
| Rated Power Input | 4.7 kW with the Pump model; 4.5 kW with the Gravity model | 4.7 kW |
| Fuse Size | 16 A | 16 A |
| Dimensions (W x D x H) | Air-cooled: 55 x 87.5 x 89 cm | 55 x 87.5 x 89 cm |
| Net Weight | 210 kg for the Pump model; 190 for the Gravity model | 210 kg |
| Refrigerant | – | R404 |
Specifications are listed on each model’s page. Ask our team to confirm the right model for your site.
The 193 range in photos
Talk to our specialists
Free demo at our Auckland showroom, machine set-up, recipe and menu development and one-on-one training. Call 0508 625 677 or send an enquiry.
