Carpigiani XVL
Floor-standing machines for express gelato and soft serve: the XVL 1 with one flavour and the XVL 3 with twin twist.
Carpigiani XVL models
Every model has its own page with full features, specifications and photos. Select a model to see it in detail.
Each XVL model
XVL 1 Classic
XVL 1 Classic.
Cooling System: Air Cooling, Water Cooling
No of Flavours: 1 Flavour
Power Supply: 400v / 50hz / 3Ph
Mix Delivery System: Pump
Cylinder Capacity: 1.75 L
XVL 1 Steel
High-performance single flavour floor-standing soft serve machine to produce more than 450 servings of 75 g in one hour.
Power Supply: 400v / 50hz / 3Ph
Cooling System: Air Cooling, Water Cooling
No of Flavours: 1 Flavour
Mix Delivery System: Pump or Gravity
Tank Capacity: 13 L
XVL 3 Classic
XVL 3 Classic Soft Serve Machine.
Cooling System: Air Cooling, Water Cooling
No of Flavours: 2 Flavours +
Power Supply: 400v / 50hz / 3Ph
Mix Delivery System: Pump
Cylinder Capacity: 1.75 L
XVL 3 Steel
Highly performing twin-twist floor-standing soft serve machine. It produces up to 600 servings of 75 g in one hour.
Power Supply: 400v / 50hz / 3Ph
Cooling System: Air Cooling, Water Cooling
No of Flavours: 2 Flavours +
Mix Delivery System: Pump or Gravity
Flavours: 2+1
XVL specifications
| Specification | XVL 1 Classic | XVL 1 Steel | XVL 3 Classic | XVL 3 Steel |
|---|---|---|---|---|
| Cooling System | Air Cooling, Water Cooling | Air Cooling, Water Cooling | Air Cooling, Water Cooling | Air Cooling, Water Cooling |
| No of Flavours | 1 Flavour | 1 Flavour | 2 Flavours + | 2 Flavours + |
| Power Supply | 400v / 50hz / 3Ph | 400v / 50hz / 3Ph | 400v / 50hz / 3Ph | 400v / 50hz / 3Ph |
| Mix Delivery System | Pump | Pump or Gravity | Pump | Pump or Gravity |
| Cylinder Capacity | 1.75 L | 1.75 L | 1.75 L | 1.75 L |
| Fuse Size | 10 A | 10 A | 16 A | 16 A |
| Refrigerant | R404 | – | R404 | – |
| Hourly Production | 465 servings of 75 g | – | 630 servings of 75 g | – |
| Rated Power Input | 2.5 kW | 2.5 kW | 5.0 kW | 5.0 for Pump version; 4.8 for Gravity version kW |
| Net Weight | 230 kg | – | 310 kg | – |
| Tank Capacity | 13 L | 13 L | 13+13 L | 13+13 L |
| Dimensions (W x D x H) | 45 x 93 x 160.5 cm | – | 50 x 93 x 160.5 cm | – |
| Flavours | – | – | 2 + 1 | 2+1 |
Specifications are listed on each model’s page. Ask our team to confirm the right model for your site.
